43.5 GHz -45.5GHz Bandpass Filter
Characteristics and Application
43.5 GHz -45.5 GHz filters have the following performance characteristics:
1. High frequency support: the filter is able to cover the high frequency range, which is suitable for 5G millimetre wave communications.
2. Ultra-wide bandwidth: The filter provides wide bandwidth as it allows higher data transmission rates.
3. Low insertion loss: The filter ensures signal integrity and communication quality.
4. High rejection performance: It can provide high out-of-band rejection to effectively filter out interference from neighbouring channels, ensuring signal purity and system stability.
5. low power consumption: helps to extend the service life of the equipment.
6. high Q: the filter has better selectivity and lower energy consumption.
As a large microwave component source factory, XST can provide cost-effective microwave products. By purchasing directly from our factory, you can save costs without compromising product quality.
Please contact us for any microwave product requirements and we will respond promptly!
Technical indicators
| Product Name | Bandpass filter |
| Frequency Range | 43.5 GHz -45.5GHz |
| Insertion loss | ≤2dB |
| VSWR | ≤1.5 |
| Rectangularity factor | ≥ 60dB@42.8 GHz |
| ≥ 60dB@46.2GHz | |
| port connector | FDP400 flange |
| Size | 54.2*mm |
| Impedance | 50 OHMS |
Nots
Filter heat dissipation issues: In high power applications, filters may generate more heat and require effective heat dissipation solutions.
Filter Environmental Adaptability: The performance of cavity filters may suffer when operating in harsh environments or over wide temperature ranges.
Good grounding of filters: The grounding of filters is critical to their performance, especially in high frequency applications. Good grounding reduces common mode interference and improves filter performance.
Filter mounting position: The filter should be located as close as possible to the power supply and load to achieve the best filtering effect. At the same time, the inputs and outputs of the filter should be effectively isolated to reduce electromagnetic coupling.
Customer Concerns
Technical Strength
With 12 years of innovation, XST now has industry-leading research and development capabilities. We invest in continuous research and development, technical training and development of our staff, and continually innovate and develop new products in order to stay at the forefront of technology and provide our customers with the latest microwave products.XST also has a skilled and experienced team, whose members have been awarded a series of patents and intellectual property rights in microwave technology, and who also collaborate with universities and research institutes in technical exchanges and joint research and development, and participate in or develop the latest standards in industry technology. XST also cooperates with universities and research institutes for technical exchanges and joint research and development, and participates in or formulates the latest standards of the industry.
Customised Solutions
We understand that each filter has its own specifications and application scenarios to meet the needs of different customers. Therefore, we offer a wide range of customisation options for our rate filter products. Including frequency range, power handling capability and mechanical design, our team is skilled in tailoring products to meet individual requirements.
We gain an in-depth understanding of our customers' specific needs, evaluate the cost-effectiveness of different solutions, and select the most cost-effective option to provide our customers with a personalised solution that is perfectly suited to their specific application. The strength of our customised products has been recognised by a number of military research institutes and research institutes and is the first choice for many customers seeking customised microwave devices.
Superior Quality
XST understands that quality is the foundation of our life, therefore, we have established a strict quality control system, every microwave product undergoes a strict quality control inspection process at the factory to ensure its performance and service life, our products are known for their excellent quality, every detail is carefully crafted to ensure that it reaches the top level of the industry. Compared to other brands, our products demonstrate a superior quality difference in terms of durability, performance and material selection. The trust and praise of countless customers is the best proof of our superior quality. Their satisfaction is the driving force behind our continuous pursuit of excellence.
Affordable Prices
XST understands that every customer has a certain budget control when purchasing products, and it is the pursuit of every customer to get the best quality products at the most affordable price. We are committed to offering the most competitive prices in the market for similar products, allowing you to enjoy high quality microwave products at the lowest cost. Although the price is attractive, we never compromise on quality and service. Our price competitiveness stems from the ultimate pursuit of efficiency and a strict cost control system to ensure that you get a great value experience at a great value price. We insist on price transparency without any hidden costs, so that you can see our price competitiveness at a glance in the comparison. We strive for the best price, and at the same time, our comprehensive after-sales service will make every cent of your money spent on value for money.
XST has become a leader in the microwave industry with excellent quality, affordable prices, and perfect service, and we look forward to working with you and providing long-term value.
