450MHz Bandpass Filter/Cavity Filter Military Quality
Characteristics and Application
XST Centre Frequency: 450MHz filters offer the following advantages:
1. high selectivity: the specific frequency of 450MHz is accurately selected, allowing signals of this frequency to pass through, while effectively suppressing signals of other frequencies.
2. low signal attenuation: the signal attenuation when passing through the filter is very small, which helps to maintain the strength and quality of the signal and reduce the loss during transmission.
3. high rejection performance: for non-centre frequency signals, the filter has high rejection performance, which can effectively filter out unwanted signals or interference and improve the purity of the signal.
4. stability: point frequency filters are usually designed to be very stable, even under different operating conditions can maintain consistent performance.
5. application flexibility: due to its high selectivity and low insertion loss characteristics, this filter can be used for a variety of applications such as wireless communications, broadcasting, test and measurement equipment.
6. easy to integrate: because of its accurate frequency selectivity, this filter can be easily integrated into more complex systems as part of the signal processing process.
Technical indicators
| Product Name | Bandpass filter |
| Frequency Range | 450MHz; (spot frequency) |
| Insertion loss | ≤7dB |
| VSWR | ≤1.5 |
| Out-of-band rejection | ≥70dB@425MHz |
| ≥70dB@475MHz | |
| port connector | SMA-K |
| Size | 40.4*12*10mm |
| Impedance | 50 OHMS |
Nots
Installation Location: The filter should be located as close as possible to the power supply and load to achieve the best filtering effect.
Impedance matching: Ensure that the input and output impedances of the filter are matched to other components in the circuit to minimise signal reflection and improve transmission efficiency.
Maintenance and care: Check and maintain the filter regularly, especially if electrolytic capacitors are used, they need to be aware of their lifespan and replaced regularly.
Avoid overloading: During use, make sure that the filter will not be damaged due to overheating or overloading, and pay attention to its power handling capacity.
Electromagnetic compatibility: The installation and wiring of the filter should take into account the electromagnetic compatibility (EMC) requirements to avoid introducing additional interference.
